8010GX2


10-Port Fully Managed Industrial Ethernet Switch, 8 RJ45 Ports 10/100/1000Base-T(X), 2 SFP Slots 1000BaseSFP+, DIN-Rail, Dual Power Input 12-48VDC, -40°C-75°C


Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

8010GX2 is designed for industrial environments requiring high security and high quality Ethernet/Fiber communication, such as industrial automation, road traffic control, etc. 8010GX2 provides 10-port full-gigabit Ethernet including 8-port Gigabit RJ45 and 2-port 100M/1G SFP. 8010GX2 provides wire-speed switching, Cyber Security, network redundancy…L2+ management software features. Full Gigabit capability and rugged industrial design ensures system high performance and reliability in harsh environments. For convenient traffic control and zero packet loss data transmission, the switch offers contemporary management and security functions.

Product Features:
Powerful 1.2GHz ARM Cotex-A9 processor
Non-blocking switch fabric design
10-port Full Gigabit Ethernet ports, including 8 Gigabit RJ45 and 2 100/1000M SFP
8 flexible Class of Service(CoS) queues
16K MAC address table
9Kb Jumbo Frame
Fiber ports support both 100M and 1000M SFP
DDM function for fiber connectivity monitoring
Energy-Efficient Ethernet for power saving
802.1X/RADIUS port-based access control
IP Security/Port Security
HTTPs/SSH Management IP secure access
Supports advanced cyber security features, 802.1X MAB, TACAS+, DHCP Snooping, IP Source Guard, Dynamic ARP Inspection, advanced Port Security & L2-L7 Access Control List
ITU G.8032 v1/v2 ERPS Ring Redundancy & HW-based CFM for quick acknowledgement while GbE copper link failure, providing 20ms recovery time and seamless restoration.
ERPSv2 available to replace legacy Ring + Chain + Dual Homing
Inter-Operability with 3rd party industrial switch and still remain fast recovery time.
Support Enhanced RSTP for large ring network topology with up to 80 switches
Various configuration paths, including WebGUI, CLI, SNMP, Modbus TCP, LLDP topology control
Layer 2 Switch features include VLAN, QoS, LACP/Trunk, Rapid Spanning Tree protocol…etc
IGMP Snooping v1/v2/v3, IGMP Query, 512 L2 Multicast Groups for video applications
Built-in DHCP Server that automatically provides and assigns IP addresses, default gateways to clients
Support Software Utilities:
    -ANMS Network Management System
    -AIAS for Configuration Management
Support Modbus TCP for monitoring in field
Rugged Design for Wayside Network Switching with Wide Power Input Range
12~48V wide power range design with redundant power input
Excellent heat dissipation design for operating in -40~75oC environments
High level EMC protection exceeding traffic control and heavy industrial standards’ requirements
IEC 61000-6-2/4 Heavy Industrial Environment
EN50121-4 railway trackside EMC compliance
